BB2200 4.5x 4.5 CONCEALED BALL BEARING HINGE
BB2200 4-1/2-Inch x 4-1/2-Inch Concealed Ball Bearing Hinge
Our BB2200 Concealed Ball Bearing Hinge combines a 4-1/2-inch x 4-1/2-inch full-mortise format with concealed bearings for commercial door applications. The bearing arrangement supports door movement while keeping the bearing components concealed within the hinge assembly. Both leaves fit into prepared recesses, one in the door and one in the frame.
Practical Uses
- Commercial interiors: Coordinate the hinge with the door's weight, dimensions, frequency of use, and closer requirements.
- Replacement projects: Replace an existing hinge only after checking leaf dimensions, mortise depth, hole pattern, and hardware compatibility.
- New door preparation: Use the correct hinge dimensions and approved layout to prepare matching door and frame recesses.
- Finish coordination: Select from the listed finish options to complement the opening's other visible hardware.
Everyday example: An office maintenance team replaces worn hinges on a frequently used door. Before choosing BB2200, the installer measures the existing hinge in its open position, checks both mortises and the screw pattern, and confirms suitability for the actual door and closer. After fitting, the team checks that the door swings freely and latches without scraping the frame.
What the Size Means
4-1/2 inches high x 4-1/2 inches wide: Hinge width is measured across the leaves with the hinge open. It is not the width of a single leaf. Match the full hinge footprint and preparation rather than assuming that another hinge of the same nominal height will fit.
Full-mortise installation: Both leaves are recessed. Check the actual leaf thickness and required mortise depth before cutting or modifying a door or frame. For replacement work, an incorrect recess depth can affect door alignment even when the height and width appear correct.
Available Finish Options
- US10A
- US10B Antique Bronze Oiled
- US15 Satin Nickel
- US26 Bright Chrome
- US26D Satin Chrome
- US3 Bright Brass
- US32D Satin Stainless Steel
Choose the required finish from the product selector. Where base material or environmental exposure is critical, confirm the exact supplied configuration rather than selecting by appearance alone.
Installation and Selection Checks
- Check the complete application: Consider door height, width, weight, construction, operating frequency, and closer or spring-hinge requirements when specifying the hinge set.
- Verify preparation: Compare the actual hinge with the door and frame mortises, screw positions, edge geometry, and required clearances.
- Support the leaf: Secure and support the door before removing existing hinges or installing replacements.
- Select suitable fasteners: Use attachment appropriate to wood or metal preparation and confirm adequate backing and thread engagement.
- Align the hinge set: Keep the hinge axes aligned and the leaves seated correctly to avoid binding.
- Test operation: Check swing, gaps, closing, and latching through the complete operating cycle after installation.
Problems It Helps Address
- Worn hinge movement: Provides a concealed-bearing replacement option when its specifications match the opening.
- Inconsistent hardware appearance: Offers multiple finish selections for a coordinated installation.
- Uncertain replacement fit: Clearly identifies the open hinge size and full-mortise arrangement for comparison before ordering.
Product Details and Care
- Part number: BB2200
- Nominal open size: 4-1/2 inches high x 4-1/2 inches wide
- Mounting type: Full mortise
- Bearing type: Concealed ball bearing
Confirm the required hinge quantity and exact supplied configuration for the project. Do not assume a non-removable pin is included; where specified, verify the NRP option before ordering. NRP uses a retaining set screw to help prevent pin removal while the door is closed.
Inspect attachment and alignment during routine maintenance. Use cleaning and lubrication methods appropriate for the supplied finish and bearing assembly. For rated openings, verify the exact hinge configuration and installation requirements for the complete door assembly rather than treating hinge selection alone as approval of the opening.
Product Reference
Commercial Hinges Catalog, BB2200 Concealed Bearing Hinge Reference
