Cal Royal 5000 x ENT00

Write A Review
Regular price $212.00
Sale price $212.00 Regular price
Unit price
Alum
US32D-Satin Stainless Steel
Ask a question

Ask a Question

* Required fields

Size guide Share

Usually Ships: 1-3 Days

5000 x ENT00 & F5000 x ENT00 Rim Exit Devices

The Cal-Royal 5000 x ENT00 combines a Grade 1 rim exit device with the ENT00 locking entry trim with handle described for this configuration. The touch bar provides operation from the exit side, while the entry trim serves the outside-access side. Select the 5000 panic configuration or F5000 fire exit configuration to suit the complete opening rather than treating them as interchangeable.

Practical Uses

Consider this configuration for compatible commercial and institutional openings in offices, schools, hospitals, and public buildings where outside entry and inside exit operation are both needed. For replacement work, compare the existing device and trim, door preparation, strike arrangement, and access requirements before ordering. Do not assume an existing cylinder, trim, or mounting pattern will match.

The listed device selections are 5000 EO 36", F5000 EO 36", 5000 EO 48", and F5000 EO 48", with Alum or US32D satin stainless steel finishes. Although the product is identified as x ENT00, the selector labels identify the base EO devices; confirm the exact trim, cylinder/keying, and package contents for the ordered configuration before installation.

Installation and Replacement

Use the installation instructions and preparation templates that match the selected device, entry trim, and strike. Verify the listed 1-3/4" door thickness and minimum 3-3/4" stile width, along with the actual door width and available mounting clearances. Check door alignment and any existing holes before drilling. The non-handed center-hub design assists installation but does not eliminate the need to check trim orientation and the complete opening.

Wood and machine screws are included; thru-bolts are standard on fire-rated models. After fitting, test touch-bar operation, outside-trim operation, latch engagement, and repeated closing and latching. Verify the entry trim's locking and keying operation against the ordered configuration. Allen-key dogging is specified for non-fire-labeled devices only.

Problems It Helps Address

  • Outside-entry requirements: The described ENT00 locking entry trim provides a handle-operated entry arrangement; verify the exact locking function before ordering.
  • Worn exit hardware: Offers a replacement option where the device, trim, strike, and preparation are compatible.
  • Frequent daily traffic: ANSI A156.3 Grade 1 construction supports demanding commercial applications.
  • Unreliable engagement from mismatched hardware: Correct device selection and strike alignment help support consistent latching.
  • Different opening requirements: Separate panic and fire exit configurations allow selection for the intended application.

During a busy day, staff can use the entry handle from outside while occupants operate the touch bar from inside. A correctly installed assembly should work with the door and closer so the opening returns and latches without binding. If the door sticks or fails to latch, inspect the entire opening rather than assuming the exit device is the only cause.

Product Details

  • Product configuration: 5000 x ENT00; F5000 fire exit device selections also listed
  • ENT00 description: Locking entry trim with handle
  • Device selections: 5000 EO and F5000 EO, in 36" and 48" options
  • Grade: ANSI A156.3, Grade 1 certified
  • Construction: Steel chassis and heavy-gauge steel rail assembly
  • Latch bolt: Stainless steel with 3/4" throw
  • Door thickness: 1-3/4"
  • Minimum stile width: 3-3/4"
  • Handing: Non-handed center-hub design
  • Finishes: Alum and US32D satin stainless steel
  • Mounting hardware: Wood and machine screws; thru-bolts standard on fire-rated models
  • Dogging: Allen-key type standard on non-fire-labeled devices

Panic, Fire, and Accessibility Considerations

The existing specifications identify UL panic and fire exit listings, with F5000 stated for use on fire-labeled doors rated up to 3 hours. They also reference ADA, UL10C, and UBC 7-2-1997. Verify the selected device, trim, current documentation, applicable listing, and complete door assembly requirements for the project. Installing this hardware alone does not establish the rating or accessibility of the complete opening.

An antimicrobial coating is described as available on US32D, but it is not shown as a separate selectable option here. Confirm availability and the exact ordered finish rather than assuming the coating is included.

Installation Instructions

Use instructions matching the ordered device and size, plus the instructions supplied for the actual ENT00 entry trim. The 5000EO36 document is labeled for that base-device configuration.

Preparation Templates

Use only templates applicable to the ordered device, strike, and entry configuration. These links do not establish that an accessory is included or that its template suits ENT00.

Catalog

View 5000 Series Catalog
